The design of cold-formed steel members according to the AISI S100-16 / CSA S136-16 is available in RFEM 6. Design can be accessed by selecting “AISC 360” or “CSA S16” as the standard in the Steel Design Add-on. “AISI S100” or “CSA S136” is then automatically selected for the cold-formed design.
RFEM applies the Direct Strength Method (DSM) to calculate the elastic buckling load of the member. The Direct Strength Method offers two types of solutions, numerical (Finite Strip Method) and analytical (Specification). The FSM signature curve and buckling shapes can be viewed under Sections.
![Effective Cross-Section in SHAPE-THIN 8](/en/webimage/006822/484232/DUENQ.png?mw=512&hash=96d43be20a4528cf741503961d2b0429d7f70ef4)
In SHAPE-THIN 8, the effective cross-section of stiffened buckling panels can be calculated according to EN 1993-1-5, Cl. 4.5.
The critical buckling stress is calculated according to EN 1993-1-5, Annex A.1 for buckling panels with at least 3 longitudinal stiffeners, or according to EN 1993-1-5, Annex A.2 for buckling panels with one or two stiffeners in the compression zone. The design for torsional buckling safety is also performed.
![Feature 002854 | Transfer of support reactions to free loads](/en/webimage/051684/3998606/1.png?mw=512&hash=9d7f6c198b6d4ae6ee8f2fa8bca75f85579e14c9)
In the "Import Support Reaction" load wizard, the "Free Loads" object connection type is available in addition to the "Manual" ones. This option saves you the task of manually assigning the support reactions to specific nodes and lines. The support forces of the connected model are applied as free loads in this option.
![Feature 002852 | Spline surface with minimum curvature](/en/webimage/051665/3996349/2.png?mw=512&hash=495637ed9f78ff76e0ac09e73585e9001cb15ebb)
You can use the "spline with minimum curvature" surface geometry type to generate curved surfaces on the basis of the control nodes in the middle of the surface.
This can be used to model terrain surfaces, for example.
