A detailed stress and deformation analysis was carried out using RFEM for this filter/dryer project with an agitator. The elaborate modeling included 1424 surfaces, 158 solids, and 425 structural components, which illustrates the complex geometry of the structure. The latest design methods ensure accurate results when analyzing the load-bearing behavior. Additional information about material properties and loading scenarios is taken into account in the model. The analytical model was created by Peter & Partner (© Peter & Partner).
Model Used in
Analysis of Industrial Filter Device
No Download Possible
Customer Project / View Only
| Number of Nodes | 3612 |
| Number of Lines | 3351 |
| Number of Members | 425 |
| Number of Surfaces | 1424 |
| Number of Solids | 158 |
| Number of Load Cases | 10 |
| Number of Load Combinations | 5 |
| Total Weight | 9,559 t |
| Dimensions (Metric) | 4.739 x 4.725 x 3.343 m |
| Dimensions (Imperial) | 15.55 x 15.5 x 10.97 feet |
| Program Version | 5.01.44 |
