Reinforced Concrete Frame Structure

Number of Nodes 21
Number of Members 24
Number of Load Cases 9
Number of Load Combinations 12
Total Weight 282,980 t
Dimensions (Metric) 72.500 x 0.500 x 20.150 m
Dimensions (Imperial) 237.86 x 1.64 x 66.11 feet
Program Version 8.01.00

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
