The model includes line release, a feature that allows for free deformation or displacement along specified lines in a structural model. This feature is crucial when decoupling structural components to simulate realistic deformations and analyze the exact load transfer. Line release can be configured in various Dlubal software modules to meet specific design requirements.
Line Release for Structural Analysis
| Number of Nodes | 8 |
| Number of Lines | 8 |
| Number of Surfaces | 2 |
| Number of Load Cases | 1 |
| Total Weight | 2.700 t |
| Dimensions (Metric) | 5.000 x 4.000 x 2.500 m |
| Dimensions (Imperial) | 16.4 x 13.12 x 8.2 feet |
| Program Version | 5.13.01 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
