FTX050 | Truss
Block parameters editable dynamically | |
Number of Nodes | 5 |
Number of Lines | 7 |
Number of Members | 7 |
Number of Surfaces | 0 |
Number of Solids | 0 |
Number of Load Cases | 1 |
Number of Load Combinations | 0 |
Number of Result Combinations | 0 |
Total Weight | 0.778 tons |
Dimensions | 29.53 x 19.69 x 0 feet |
