TMS029 | Tensile Membrane Structure
| Block parameters editable dynamically | |
| Number of Nodes | 12 |
| Number of Lines | 23 |
| Number of Members | 21 |
| Number of Surfaces | 5 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 1.119 tons |
| Dimensions | 42.65 x 24.61 x 49.21 feet |
