The file to download contains a parametrized model saved as a block (*.rfs file type). For more information about the parametrized models and blocks, see the Short Video Tutorial - SVT 010 | Creating and Importing Blocks - see the link below.
The model was created by the technical team of Dlubal Latam.
Tube with Bolts
| Block parameters editable dynamically | |
| Number of Nodes | 82 |
| Number of Lines | 69 |
| Number of Members | 4 |
| Number of Surfaces | 44 |
| Number of Solids | 4 |
| Number of Load Cases | 0 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.120 tons |
| Dimensions (Metric) | 1.410 x 0.300 x 0.300 m |
| Dimensions (Imperial) | 4.63 x 0.98 x 0.98 feet |
