This model represents a steel silo featuring a circular base structure and a truncated cone-shaped roof. Such a design is typically utilized for the storage of bulk materials, efficiently leveraging the mechanical properties of steel for structural stability and durability. Ideal for engineering analyses, this model can be used to investigate load distributions and material stresses within silo construction.
Steel Silo with Circular Plan and Cone Roof
| Block parameters editable dynamically | |
| Number of Nodes | 6 |
| Number of Lines | 6 |
| Number of Members | 0 |
| Number of Surfaces | 4 |
| Number of Solids | 0 |
| Number of Load Cases | 2 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 73.422 tons |
| Dimensions (Metric) | 11.000 x 6.500 x 11.000 m |
| Dimensions (Imperial) | 36.09 x 21.33 x 36.09 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
