This model of a steel hall was created in the online training “RFEM 6 Tutorial for Beginners” and reflects the state of the video “Creating New Model – Base Data”. It can be opened and analyzed using the finite element analysis software RFEM. The structure is based on common principles of steel structures and provides a practical insight into the design of halls. The model description is well-founded and shows typical features of modern steel halls.


(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

Steel Hall from Online Training | 09

Number of Nodes 60
Number of Lines 87
Number of Members 87
Number of Surfaces 0
Number of Solids 0
Number of Load Cases 1
Number of Load Combinations 4
Number of Result Combinations 0
Total Weight 13,724 t
Dimensions (Metric) 15,000 x 6,500 x 15,000 m
Dimensions (Imperial) 49.21 x 21.33 x 49.21 feet

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
