This thesis deals with the structural analysis and design of a steel structure for the completion of the Šutka swimming complex in Prague, Czech Republic. This graduation thesis project was divided into two parts. The first proposed structure is a roof of the waterpark. The structure consists of a separate building, which is connected to the existing building of the Šutka swimming pool.
Structural Analysis and Design of Steel Extension of the Šutka Swimming Complex in Prague
| Number of Nodes | 316 |
| Number of Members | 618 |
| Number of Load Cases | 9 |
| Number of Load Combinations | 67 |
| Number of Result Combinations | 2 |
| Total Weight | 59.419 tons |
| Dimensions | 158.79 x 172.57 x 38.91 feet |
| Program Version | 7.02.03 |
Customer Project
Customer Project
Knowledge Base
The material database in RFEM, RSTAB and SHAPE-THIN contains steels according to the Australian standard AS/NZS 4600:2005.
In the "Edit Section" dialog box, you can display the buckling shapes of the Finite Strip Method (FSM) as a 3D graphic.
- Design of five types of seismic force-resisting systems (SFRS) includes Special Moment Frame (SMF), Intermediate Moment Frame (IMF), Ordinary Moment Frame (OMF), Ordinary Concentrically Braced Frame (OCBF), and Special Concentrically Braced Frame (SCBF)
- Ductility check of the width-to thickness ratios for webs and flanges
- Calculation of the required strength and stiffness for stability bracing of beams
- Calculation of the maximum spacing for stability bracing of beams
- Calculation of the required strength at hinge locations for stability bracing of beams
- Calculation of the column required strength with the option to neglect all bending moments, shear, and torsion for overstrength limit state
- Design check of column and brace slenderness ratios
The seismic design result is categorized into two sections: member requirements and connection requirements.
The "Seismic Requirements" include the Required Flexural Strength and the Required Shear Strength of the beam-to-column connection for moment frames. They are listed in the ‘Moment Frame Connection by Member’ tab. For braced frames, the Required Connection Tensile Strength and the Required Connection Compressive Strength of the brace are listed in the ‘Brace Connection by Member’ tab.
The program provides the performed design checks in tables. The design check details clearly display the formulas and references to the standard.
