Fly Brace Connection
| Number of Nodes | 17 |
| Number of Lines | 16 |
| Number of Members | 16 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 4 |
| Number of Result Combinations | 0 |
| Total Weight | 1.008 tons |
| Dimensions | 32.81 x 0 x 32.81 feet |
