This model showcases the structural design of a warehouse storage rack frame featuring a double-sided cantilever configuration. The design focuses on optimizing storage capacity by offering dual access sides, providing a flexible solution for bulk goods. Aimed at safe and efficient storage solutions, the model illustrates engineering precision applicable in warehouse settings.
Warehouse Storage Rack Frame Double-Sided Cantilever
| Block parameters editable dynamically | |
| Number of Nodes | 76 |
| Number of Lines | 69 |
| Number of Members | 69 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 1.053 tons |
| Dimensions (Metric) | 3.600 x 4.900 x 2.600 m |
| Dimensions (Imperial) | 11.81 x 16.08 x 8.53 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
