This structural model features a column base with four inclined rectangular hollow section (RHS) columns. The design includes a base plate and stiffeners for enhanced stability. Secure anchoring is also a key component of this setup to ensure robust support. This model highlights critical elements for optimizing column support systems.
Column Base with Four Inclined RHS Columns
| Number of Nodes | 5 |
| Number of Lines | 4 |
| Number of Members | 4 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 0 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.106 tons |
| Dimensions (Metric) | 1.200 x 1.000 x 1.200 m |
| Dimensions (Imperial) | 3.94 x 3.28 x 3.94 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
