The model showcases a textile membrane structure supported by a steel framework. It employs the Form-Finding add-on in RFEM 6 for optimal shape calculation, a process crucial for the stability of lightweight structures. This tool allows for precise determination of the equilibrium shape under the given prestress and loads, ensuring accurate simulation and visualization. Ideal for those interested in modern architectural designs using membranes.
Textile Membrane Structure on Steel Frame
| Number of Nodes | 25 |
| Number of Lines | 30 |
| Number of Members | 30 |
| Number of Surfaces | 6 |
| Number of Solids | 0 |
| Number of Load Cases | 2 |
| Number of Load Combinations | 7 |
| Number of Result Combinations | 0 |
| Total Weight | 3.337 tons |
| Dimensions (Metric) | 32.000 x 6.218 x 27.713 m |
| Dimensions (Imperial) | 104.99 x 20.4 x 90.92 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
