RFEM | Structural dynamics and earthquake design according to EC 8
Information about online training
Why an online training?
Online group training sessions provide the opportunity to gain expert knowledge and to ensure you’re getting the most out of your Dlubal programs.
Date | Time
ContentOnline basic training on earthquake design according to Eurocode 8 using the FEM static program RFEM
In this training you will learn the basics of structural dynamics and the most important verification methods for earthquake design. Using a practical example, the multi-modal response spectrum method and its implementation in RFEM and the associated modules of the RF-DYNAM Pro series is explained. Open questions can be discussed.
Price195.00 EUR net, excluding VAT
|-||Overview of possible design methods|
|-||Multi-Modal response spectrum analysis|
|-||Practical example 1: Response spectrum analysis|
|-||Dynamic actions on structures|
|-||Practical example 2: Machine induced vibrations|
- Training certificate
- Training presentation for download
- Used models for download
- Video recording of the training
Stine Effler, M.Sc.
Product Engineering & Customer Support
Ms. Effler is responsible for the development of products for dynamic analysis and provides technical support for our customers.
Dipl.-Ing. (FH) Stefan Frenzel
Product Engineering & Customer Support
Mr. Frenzel is responsible for the development of products for dynamic analysis. He also provides technical support for customers of Dlubal Software.
Do you have any questions about a group training course? Contact us via phone, email, chat, or forum.
If you are interested in a specific topic not included in a group training, consider an Individual Training.Individual Training
