Question:
In spite of having defined average regions, they are not considered in the design in RF‑LAMINATE Surfaces. Which setting did I overlook?
Answer:
In order to consider the average regions in the design in RF‑LAMINATE Surfaces, it is always necessary to activate them in the detailed settings of the add-on module. See Image 01 with the detailed settings in RF‑LAMINATE.
