FAQ 004285 | When performing an analysis in RF‑STABILITY, I get the message "The stiffness matrix is singular! The structure is unstable. Instability found in FE mesh node XY." How can I find this FE mesh node?

Video

First Steps with RFEM

First steps

We provide hints and tips to help you get started with the RFEM program.

13 December 2019

001097

René Flori

Please accept Marketing Cookies to watch this video.

Question

When performing an analysis in RF‑STABILITY, I get the message "The stiffness matrix is singular! The structure is unstable. Instability found in FE mesh node XY." How can I find this FE mesh node?

Answer

In RFEM, it is possible to search for FE mesh nodes by using the menu "Edit"→ "Find via Number." An existing FE mesh is required, of course.
