Question:
Is it also possible to transfer loads and load cases using the .stp interface (regulated according to DSTV)?
Answer:
Yes, it is possible. Usually, only individual members of a large system are exported to perform detailed analyses on them. You can find more information about this export in another FAQ (see Downloads below).
The export of a member with loads is shown in the attached video.
