Question:
How do I influence the x-locations in the result tables for members?
Answer:
The x-locations (a distance of the member division points) are defined by the member division. You can define additional member divisions in the dialog box, in Table 1.6, or in Table 1.16.
Member divisions allow the definition of points on members on which the internal forces and deformations are displayed in the result tables and in the numerical printout. The member division does not have an influence on the determination of the extreme values or on the graphical result diagram (RFEM internally uses a finer division). Therefore, member divisions are not necessary in most cases.
Note: The member division for the graphical result diagram is controlled by the global calculation parameters.
