Question:
When I select a surface by clicking it, the nodes and lines belonging to the surface are not included in the selection. Is there any possibility to integrate them?
Answer:
Sometimes it is necessary to add related objects, such as nodes and lines of a surface, to the selection in order to edit parts of the model. To do this, simply use the following function:
Menu "Edit" → "Select" → "Related Objects".
