Question:
What should be considered when using a failure of columns under tension in the RF‑/DYNAM Pro – Equivalent Loads add-on module?
Answer:
In order to consider the failure of certain members when using RF‑/DYNAM Pro – Equivalent Loads, proceed as follows:
1) Deactivating the corresponding members for the eigenvalue determination within the corresponding load case; see Image 01 (add-on module, tab Natural Vibration Cases, Calculation Parameters) and Image 02 (main program, Calculation Parameters, Deactivate and select).
2) Determining dynamic load cases from RF‑/DYNAM Pro by using the calculation, then deactivating the corresponding member in the main program within the global calculation parameters of the dynamic load cases; see Image 03.
