Question:
Does RFEM 6 include the combinations for road bridges according to EN 1991‑2?
Answer:
No, not yet. The combinations according to EN 1991‑2 are still being worked on. However, RFEM 6 provides the option to open a structure created in RFEM 5 and to import the combinations contained there. In this context, an RFEM 5 file can be used as a template for the manual combinations for bridges in RFEM 6; see the image.
