In the last video of our online course, we will learn how to model a parametric membrane structures in Rhino & Grasshopper and export the results to RFEM 6.
Time Schedule:
00:00 Introduction
00:20 Geometry
07:40 Groups
08:14 Parameters
08:47 Members
09:14 Section
09:45 Material
10:17 Export
12:07 Surfaces
12:55 Thickness
14:30 Supports
Rhinos are considered stubborn and inflexible. Rhino is clearly the exception. The bidirectional interface RFEM 6 - Rhino allows you to transfer various line types as well as surfaces (plane, rotated surface, and NURBS).
Also the bidirectional Grasshopper interface allows you to export and import model data, load cases and combinations, and the loads themselves. Instead of volatility, you will find a stable connection that you cannot build on, but that allows you to plan ahead.
RFEM 6 Interfaces to Rhino & Grasshopper
Using the "Beam Panel" thickness type, you can model timber panel elements in 3D space. You just specify the surface geometry and the timber panel elements are generated using an internal member-surface construct, including the simulation of the connection flexibility.
