Question:
How can I open calculation diagrams in RFEM 6 or RSTAB 9 after a successful calculation?
Answer:
During the calculation, you can find the convergence diagram in the solver window of RFEM 6 and RSTAB 9, see Image 01.
► Image | RFEM 6 | Solver Window https://www.dlubal.com/en/img/038727
To insert and edit such calculation diagrams, a new main group has been introduced. You can find them under the Loads group in the Data navigator. You can also open the calculation diagrams in the result tables, if they have been defined, see Image 02.
► Image | After defining calculation diagrams, you can also open them in the result tables. https://www.dlubal.com/en/img/038728
Would you like to calculate a load case or a combination in several load increments? Then activate the "Save results of all load increments" option in Static Analysis Settings, see Image 03. Otherwise, only the results of the highest increment are displayed in the calculation diagram.
► Image | Option to Save Results of All Load Increments in Static Analysis Settings https://www.dlubal.com/en/img/038730
The "Edit Calculation Diagram" dialog box is shown in Image 04.
► Image | Dialog Box "Edit Calculation Diagram" https://www.dlubal.com/en/img/038731
