Question:
How do I exclude specific Load Combinations (COs) in the design add-on?
Answer:
In the Load Combinations tab, select the Load Combinations (COs) to be excluded and then uncheck the "To Solve" option (Figure 01).
Alternatively, the COs or RCs (Result Combinations) can be excluded in the table of the Design add-on (Figure 02).
