How is it possible to control in RF‑LOAD‑HISTORY whether the deformations of the individual load steps are determined separately in each load step or added?

Answer

This setting is available in the RF‑LOAD‑HISTORY add-on module under "Details" → "Options" → "Type of Deformation," see Figure 01.

The "In particular load step" type of deformations displays the deformations of each individual load step separately, the "On undeformed structure" type shows the sum of all load steps.
