Reinforcement Description
Is it possible to display the reinforcement description in RFEM 6?
Answer
Yes, it is possible to also perform punching shear designs for vertical walls. To display the reinforcement description, click the Display navigator, and under "Model" → "Types for Concrete Design" → "Member Reinforcement," select:
- "Description on -z(top)" to display the description of the upper longitudinal reinforcement,
- "Description on +z(bottom)" to display the description of the lower longitudinal reinforcement,
- "Total Description" to display the description of the uniformly distributed longitudinal reinforcement,
- "Description" to display the description of the stirrup reinforcement.
Keywords
Answer
Yes, it is possible to also perform punching shear designs for vertical walls. To display the reinforcement description, click the Display navigator, and under "Model" → "Types for Concrete Design" → "Member Reinforcement," select:
- "Description on -z(top)" to display the description of the upper longitudinal reinforcement,
- "Description on +z(bottom)" to display the description of the lower longitudinal reinforcement,
- "Total Description" to display the description of the uniformly distributed longitudinal reinforcement,
- "Description" to display the description of the stirrup reinforcement.
Description Reinforcement Display
