RF-/STEEL IS | Features

Product Feature

  • Design of tension, compression, bending, shear, and combined internal forces
  • Stability analysis of flexural buckling and lateral torsional buckling
  • Automatic determination of critical buckling loads and critical buckling moments for general load applications and support conditions by means of a special FEA program (eigenvalue analysis) integrated in the module
  • Optional application of discrete lateral supports to beams
  • Automatic cross-section classification (Class 1 to 3)
  • Deformation analysis (serviceability)
  • Cross-section optimization
  • Wide range of cross-sections available, for example rolled I-sections, C-sections, rectangular hollow sections, angles, double angles (arrangement with flange on flange), T-sections, and welded cross-sections: I-shaped (symmetrical and asymmetrical about major axis), channel sections (symmetrical about major axis), rectangular hollow sections (symmetrical and asymmetrical about major axis), angles, round pipes, round bars
  • Clearly arranged result windows
  • Detailed result documentation including references to design equations of the standard
  • Various filter and sorting options of results including result lists by member, cross-section, x-location, or by load cases, load and result combinations
  • Result window of member slenderness and governing internal forces
  • Parts list with weight and solid specifications
  • Seamless integration in RFEM/RSTAB
  • Metric and imperial units

Contact us

Contact to Dlubal

Do you have questions or need advice?
Contact our free e-mail, chat, or forum support or find various suggested solutions and useful tips on our FAQ page.

+49 9673 9203 0

info@dlubal.com

RFEM Steel and Aluminium Structures
RF-STEEL IS 5.xx

Add-on Module

Design of steel members according to the Indian standard IS 800:2007

Price of First License
1,480.00 USD
