Determine the torsional constant for cross-section of the tube (annular area) analytically and compare the results with the numerical solution in RFEM 5 and RSTAB 8 for various wall-thickness.
Verification Example 000001 | 3
| Number of Nodes | 6 |
| Number of Lines | 3 |
| Number of Members | 3 |
| Total Weight | 0.030 tons |
| Dimensions | 3.28 x 0.66 x 0 feet |
| Program Version | 5.05.33 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
