Determination of the maximum deflection of a three-dimensional block fixed at both ends. Block is divided in the middle: The upper half is made of an elastic material and the lower part is made of timber - an elastoplastic orthotropic material with the yield surface described according to the Tsai-Wu plasticity theory. The block's middle plane is subjected to vertical pressure.
Verification Example 000009 | 4
| Number of Nodes | 6 |
| Number of Lines | 7 |
| Number of Surfaces | 2 |
| Number of Load Cases | 1 |
| Dimensions | 0.16 x 0 x 6.56 feet |
| Program Version | 5.05.00 |
