Two simple examples illustrate the problems in the member-surface connection, as shown in LC3 of the article linked below.
Model Used in
FEA Model with Problems in Connection Between Member and Surface
| Number of Nodes | 12 |
| Number of Lines | 11 |
| Number of Members | 2 |
| Number of Surfaces | 2 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 6.450 tons |
| Dimensions (Metric) | 7,500 x 2,000 x 3,000 m |
| Dimensions (Imperial) | 24.61 x 6.56 x 9.84 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
