The model represents a typical truss bridge with a focus on truss structures. It integrates the SVT method to precisely determine internal forces and combines this scheme with a proven combination approach. The analysis concept supports engineers in the realistic simulation and evaluation of complex structures. This methodical additional function provides users with advanced insights into the load-bearing behavior of the bridge.
Model Used in
Truss Bridge with SVT Combination Scheme
| Number of Nodes | 34 |
| Number of Members | 78 |
| Number of Load Cases | 5 |
| Number of Load Combinations | 17 |
| Number of Result Combinations | 1 |
| Total Weight | 2,413 t |
| Dimensions (Metric) | 22.332 x 4.500 x 7.830 m |
| Dimensions (Imperial) | 73.27 x 14.76 x 25.69 feet |
| Program Version | 8.24.00 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
