This model deals with the welding processes in steel structures and uses a steel frame to illustrate the practical applications of welded joints. The 2D model provides a clear visualization of the structural details and shows the use of modern software methods like RFEM. By repeating the welding process, the focus is placed on precise connections, which is essential for the safety and durability of the structures. Overall, the model provides a practical insight into the efficient implementation of welding techniques in steel structures.
Model Used in
Welding Technology in Steel Structures 2D
| Number of Nodes | 114 |
| Number of Lines | 190 |
| Number of Surfaces | 87 |
| Number of Solids | 12 |
| Number of Load Cases | 1 |
| Total Weight | 0,151 t |
| Dimensions (Metric) | 1.030 x 0.250 x 0.750 m |
| Dimensions (Imperial) | 3.38 x 0.82 x 2.46 feet |
| Program Version | 5.10.01 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
