The model represents an elegant vault characterized by a convex three-dimensional shape with a prominent longitudinal axis. It stands out with its clear geometric definition and sophisticated design. The linked image shows the component from different perspectives, revealing fine structural details. The design is ideal as a comparison example in innovative structural analyses. The precise execution allows versatile applications in building construction.


(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

Convex Vault

Number of Nodes 10
Number of Lines 9
Number of Surfaces 2
Number of Load Cases 1
Total Weight 36,291 t
Dimensions (Metric) 11.935 x 6.935 x 6.935 m
Dimensions (Imperial) 39.16 x 22.75 x 22.75 feet
Program Version 5.24.02

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
