The file to download contains a parametrized model saved as a block (*.rfs or *.rf6 file type). For more information about the parametrized models and blocks, see the Short Video Tutorial - SVT 010 | Creating and Importing Blocks - see the link below.
The model was created by the technical team of Dlubal Latam.
3-Bay Masonry Wall
Block parameters editable dynamically | |
Number of Nodes | 8 |
Number of Lines | 10 |
Number of Members | 10 |
Number of Surfaces | 3 |
Number of Solids | 0 |
Number of Load Cases | 0 |
Number of Load Combinations | 0 |
Number of Result Combinations | 0 |
Total Weight | 7.290 tons |
Dimensions | 29.53 x 9.19 x 0 feet |
