Straight stairs with 1 landing and 2 flights and beam
Model to Download
The file to download contains parametrized model saved as block (*.rfs file type). For more information about parametrized models and blocks see the Short Video Tutorial - SVT 010 | Creating and Importing Blocks - see the link below.
Model created by the technical team of Dlubal Latam.
The calculation of complex structures by means of finite element analysis software is generally performed on the entire model. However, the construction of such structures is a process carried out in multiple stages where the final state of the building is achieved by combining the separate structural parts. To avoid errors in the calculation of overall models, the influence of the construction process must be considered. In RFEM 6, this is possible by using the Construction Stages Analysis (CSA) add-on.
