Database of Foundation Templates
In RFEM 5 as well as RSTAB 8 in RF-/FOUNDATION Pro, you can save the foundation dimensions for all five foundation types as foundation templates in a user-defined database and use them later in other models.
New
Steel Joints | Stability Analysis Software
For the joint components, it is possible to check whether the stability failure is relevant (requires the Structure Stability add-on for RFEM 6 / RSTAB 9).
In this case, the critical load factor for all analyzed load combinations and the selected number of mode shapes is calculated for the connection model. The smallest critical load factor is compared with the limit value 15 from the standard EN 1993‑1‑1, Clause 5. Furthermore, a user-defined adjustment of the limit value is possible. Moreover, the corresponding mode shapes are displayed graphically as the result of the stability analysis.
For the stability analysis, an adapted surface model is used to specifically recognize the local buckling shapes. The model of the stability analysis, including the results, can also be saved and used as a separate model file.
- I do not want to design a cross-section in the RF‑/STEEL EC3 add-on module. Can I quickly remove this cross-section from the selection?
- Are the models and presentations from Info Day 2018 freely available, and can you send them to me?
- I design a set of members by using the equivalent member method in RF‑/STEEL EC3, but the calculation fails. The system is unstable, delivering the message "Non-designable - ER055) Zero value of the critical moment on the segment."What could be the reason?
- My aim is to mesh a circular hole plate in a mapped way. Is such a meshing possible in RFEM?
- I have a trapezoidal roof structure supported by beams. However, the moments on the beams are smaller than they should be. What could be the reason for this?
- Is it possible to divide a free surface load by the existing lines in RFEM?
- I design a cross-section created in the SHAPE‑THIN program by using the design add-on module, but the program shows the error message "ER006 Invalid type of c/t-part for cross-section of type General." What can I do?
- How do I display some results of all load cases in the printout report, but other results of the selected load cases only?
- Why are some load cases displayed in red in RF‑STEEL EC3?
- Why are the equivalent member designs grayed out in the Stability tab when activating the plastic designs by using the partial internal force method (RF‑/STEEL Plasticity)?
