Concrete Structure of Building | Model B

Description

Model B of the graduation thesis "BIM in Structural Engineering...".

Model Used in

Graduation Thesis 000445 | BIM in Structural Engineering: A Study of Interoperability Between BIM Platform and FEM Software on Structural Modelling, Analysis and Design

Write Comment...

Write Comment...

Number of Nodes 28
Number of Lines 44
Number of Members 44
Number of Surfaces 0
Number of Solids 0
Number of Load Cases 8
Number of Load Combinations 24
Number of Result Combinations 0
Total Weight 172,740 t
Dimensions 7,200 x 13,600 x 20,300 m

Disclaimer

Models to Download

This structural analysis model available for download may be used for learning or testing purposes. There is no guarantee or liability for the accuracy or completeness of the model.
