Base Plate Connection | AISC
Model to Download
Description
Download the base plate connection model here and open it with the FEA software RFEM.
This model is used in the free webinar "Member, Surface, and Solid Stress-Strain Analysis in RFEM 6" on July 26, 2022 (English).
Keywords
Free webinar Member Surface Solid Stress Strain Nonlinear Plastic Von Mises
Write Comment...
Write Comment...
- Views 387x
- Downloads 41x
- Updated 26 July 2022
- Number of Nodes 26
- Number of Lines 29
- Number of Members 0
- Number of Surfaces 11
- Number of Solids 0
- Number of Load Cases 2
- Number of Load Combinations 1
- Number of Result Combinations 0
- Total Weight 0,078 t
- Dimensions 0,508 x 1,016 x 0,508 m
Disclaimer
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
