Hybrid Structure System | Superposition System | Superposition of section-active and form-active structure systems | Cable supported hinged frames | Two-hinged frame with bilateral cable support


(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

HSS008-b | Hybrid Structure System

Block parameters editable dynamically
Number of Nodes 68
Number of Lines 100
Number of Members 90
Number of Surfaces 3
Number of Solids 0
Number of Load Cases 1
Number of Load Combinations 0
Number of Result Combinations 0
Total Weight 389.698 tons
Dimensions 78.74 x 32.81 x 118.11 feet

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
