Concrete single-flight staircase supported by a central spine beam with bottom and top landing. The spine beam runs underneath the treads of the staircase and is anchored to the surrounding structure, providing stability and support.
STC033 | Single-Flight Staircase with Bottom and Top Landing
| Block parameters editable dynamically | |
| Number of Nodes | 58 |
| Number of Lines | 58 |
| Number of Members | 0 |
| Number of Surfaces | 10 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 2.818 tons |
| Dimensions (Metric) | 1,200 x 1,660 x 4,325 m |
| Dimensions (Imperial) | 3.94 x 5.45 x 14.19 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
