This model features a concrete staircase with a single flight in a cylindrical shape, designed with a left-hand orientation and includes a midlanding. Such structures are common in modern architecture due to their aesthetic appeal and functional design, offering a seamless transition between floors. The model demonstrates the structural analysis capabilities for such complex geometries, suitable for integration in residential and commercial buildings.
Concrete Single-Flight Cylindrical Staircase with Midlanding
| Block parameters editable dynamically | |
| Number of Nodes | 88 |
| Number of Lines | 96 |
| Number of Members | 0 |
| Number of Surfaces | 9 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 19.907 tons |
| Dimensions (Metric) | 10.000 x 4.100 x 5.000 m |
| Dimensions (Imperial) | 32.81 x 13.45 x 16.4 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
