This model is used in KB 001846 to present the RFEM 6-specific function by which you can assign an eccentricity to the nodal supports and thus influence the determination of the effective length considered in the stability analysis.
KB 001846 | Timber Beam
| Number of Nodes | 4 |
| Number of Lines | 1 |
| Number of Members | 1 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 0 |
| Total Weight | 1.693 tons |
| Dimensions | 59.06 x 0 x 0 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
