Parameterization of the geometry of a rectangular plate connection, connected by two plates linked by ten bolts.
A model created by the Dlubal Latam engineering team. The model is also available as a parameterized block on the Dlubal Latam website.
Connection of Plates
| Block parameters editable dynamically | |
| Number of Nodes | 160 |
| Number of Lines | 130 |
| Number of Members | 10 |
| Number of Surfaces | 84 |
| Number of Solids | 4 |
| Total Weight | 0.022 tons |
| Dimensions | 1.98 x 0.15 x 0.43 feet |
| Program Version | 5.28.01 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
