This model illustrates a strap beam combined footing foundation, ideal for distributing structural loads. The configuration efficiently combines the properties of a continuous beam with isolated footings. The design ensures load transfer and distribution across combined footings, optimizing stability and reducing differential settlement. Ideal for projects requiring enhanced foundation support under complex load conditions.
Strap Beam Combined Footing Foundation
| Block parameters editable dynamically | |
| Number of Nodes | 32 |
| Number of Lines | 48 |
| Number of Members | 0 |
| Number of Surfaces | 24 |
| Number of Solids | 4 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 11.625 tons |
| Dimensions (Metric) | 12.000 x 0.500 x 2.000 m |
| Dimensions (Imperial) | 39.37 x 1.64 x 6.56 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
