This model showcases a structural design featuring a column base and column using circular hollow sections (CHS). The configuration includes two CHS diagonals connected to a base plate with welded diagonal connections. Additionally, anchoring techniques are integrated to ensure stability and support in structural applications.
Column Base with Two Diagonals of Vertical Bracing
| Number of Nodes | 4 |
| Number of Lines | 3 |
| Number of Members | 3 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 0 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.050 tons |
| Dimensions (Metric) | 1,200 x 1,000 x 0,000 m |
| Dimensions (Imperial) | 3.94 x 3.28 x 0 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
