The model represents a torsion structure with a hollow steel box girder and bored piles. The torsion girder ensures load transfer from the noise barrier, which is connected by a screw connection, without placing any load on the existing bridge.
Torsion Beam with Cantilever Brackets on Bored Piles
| Number of Nodes | 130 |
| Number of Lines | 203 |
| Number of Members | 28 |
| Number of Surfaces | 75 |
| Number of Solids | 0 |
| Number of Load Cases | 6 |
| Number of Load Combinations | 16 |
| Number of Result Combinations | 2 |
| Total Weight | 99.206 t |
| Dimensions (Metric) | 0.700 x 14.550 x 26.000 m |
| Dimensions (Imperial) | 2.3 x 47.74 x 85.3 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
