The model shows the complex structure of a concrete abutment for a bridge. This structural element is essential for transferring the bridge’s load into the ground and ensures the stability of the entire load-bearing structural system. The model is used to analyze the load capacity and deformation behavior of the structure. Three-dimensional modeling helps identify potential weak points early on and optimize the design.
Concrete Bridge Abutment
| Number of Nodes | 51 |
| Number of Lines | 45 |
| Number of Members | 16 |
| Number of Surfaces | 8 |
| Number of Solids | 0 |
| Number of Load Cases | 0 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 623.507 t |
| Dimensions (Metric) | 5.820 x 26.100 x 11.000 m |
| Dimensions (Imperial) | 19.09 x 85.63 x 36.09 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
