Have you ever faced challenges in modeling details of a steel joint, especially when a component is cut and welded inside a junction plate, as shown in the connection below❓
We're excited to introduce a new sheet metal cutting method! Our development team is continuously working to provide you with unlimited modeling options. 🔩
Start modeling your connections within the comprehensive structural analysis All-In-One place - RFEM 6!
Product Feature
Product Feature
Product Feature
Product Feature
Product Feature
Product Feature
In the Steel Joints add-on, you can perform precise cuts on plates and structural components using the "Auxiliary Solid" component. Within this component, you can use the shapes of a box, a cylinder, or any cross-section as a guide object.
Go to Explanatory Video
In the Steel Joints add-on, you can classify the joint stiffness.
In addition to the initial stiffness, the table also shows the limit values for hinged and rigid connections for the selected internal forces N, My, and/or Mz. The resulting classification is then displayed in tables as "hinged", "semi-rigid", or "rigid".
Go to Explanatory Video
In the Steel Joints add-on, you have this option to consider the preloaded bolts in the calculation of all components.
You can easily activate the prestress using the check box in the bolt parameters, and it has an impact on the stress-strain analysis as well as the stiffness analysis.
Go to Explanatory Video
In the Member Editor component, you can also select the entire member as the modifying object instead of the individual member plates. This way, you can apply both operations "Notch" and "Chamfer" to several member plates.
