Question:
I would like to define a nodal support displaceable in X', but the selection is grayed out. Why?
Answer:
If you cannot freely select all directions of the nodal support, you should check in General Data whether you have selected the 3D model type. In a 2D surface, certain directions of the support are blocked.
